HOP6862-54XC-48 Ports 10G-2 Ports 40G-4 Ports 100G uplink switch
HOP6862-54XC-48P10G-2P40G-4P100G
The HOP6862-54XC switch has 48 ports with 10G of capacity, 2 ports with 40G of capacity, and 4 ports with 100G of capacity. The switch is made by HOUPER Company. It is one of the HOP6862 series core layer switches. It is an extraordinary equipment that provides the possibility of communication up to 1.92T switching capacity to respond to special applications such as data centers and large organizations. It is a layer 3 switch that supports all types of routing and switching protocols. The modular design of the device helps you to make this device homogeneous and compatible with your network. The extremely high security of this switch allows you to install it in special networks.
The HOP6862-54XC switch has 48 ports with 10G of capacity, 2 ports with 40G of capacity, and 4 ports with 100G of capacity. The switch is made by HOUPER Company. It is one of the HOP6862 series core layer switches. It is an extraordinary equipment that provides the possibility of communication up to 1.92T switching capacity to respond to special applications such as data centers and large organizations. It is a layer 3 switch that supports all types of routing and switching protocols. The modular design of the device helps you to make this device homogeneous and compatible with your network. The extremely high security of this switch allows you to install it in special networks.
Specifications :
- Ultra-high density 10 Gigabit optical port access,48*10 Gigabit optical ports,2*40Goptical ports,4*100Goptical ports;
- 1.92T super high switching capacity to meet the ultra-high bandwidth application
- requirements of operator aggregation, enterprise network and data center
- Support rich service features, L2,L3,MPLS,VxLAN,OAM/APSand other features
- Supports security and flow control features, hardware-based NetFlow, and high-precision clock features
- Support elastic stacking function to achieve unified management, upgrade and maintenance of multiple devices;
- Modular design of the whole machine, pluggable design of fans and power supply components;
- Support IPv4/IPv6 dual-stack platform, support RIP/OSPF/RIPng/OSPFv3/PIM and other routing protocols
- Support VRRP/ERPS/MSTP/FlexLink/MonitorLink and other link redundancy and network redundancy protocols;
- Support ACL security filtering mechanism, provide MAC, IP, L4 port and port level security control functions
- Support Ethernet OAM802.3ag(CFM),802.3ah(EFM) and other Ethernet link detection mechanisms
- Supports remote user authentication based on Tacacs+/Radius, and supports Local user authentication
- Supports SP/WRR/SP+WRR priority algorithm to ensure the transmission of various priority traffic flows on demand
- Support IPv4/IPv6 static routing function;
- Supports multi-port mirroring analysis and service flow-based image analysis.
- Support static and flexible QinQfunction;
- Support IPV4/6unicast routing in the policy, support flexible forwarding policy;
- Supports CLI command line management based on serial port, Telnet, and SSHv2 mode
- Support RFC1213 SNMP network management;
- Supports configuration management based on WEB pages;
With 48 10 Gb ports and exclusive 40 and 100 Gb uplinks, the switch supports any type of bandwidth routing method. It is suitable for centers with a high number of requests, especially data centers.
In addition, the switch can be used as a router in 100 gigabit and 40 gigabit communications for uplink, and it will be a safe and stable device for data centers.
Product Specifications:
Physical Interface:
10 Gigabit optical port: 48*10 Gigabit optical ports, 10 Gigabit optical port adaptive connection Gigabit optical, type SFP/SFP+/LC;
Uplink optical ports: 2 40 uplink optical ports, type QSFP. 4 x 100 uplink optical ports, type QSFP28;
Console port: manage serial port, used for command line management, type RS232;
AUX debug port: out-of-band management interface for Telnet/SSH/WEB login control, type RJ45;
Working environment:
Operating temperature: -15C~55C;
Storage temperature: -40C~70C;
Relative humidity: 10%~90%, non-condensing;
Power consumption:
Power supply specifications: 1+1 redundant power supply, AC/DC optional;
Input power: AC: input 90~ 264V, 47 ~ 67Hz; DC: -36V~ -72V；
Power consumption of the whole machine: full load power consumption ≤ 180W, idle power consumption ≤25W;
Mechanical structure:
Chassis shell: metal shell, air-cooled heat dissipation;
Power supply fan: modular design of power supply and fan, support hot swappable, support fan speed control and alarm detection;
Chassis size: dimensions (length * width * height) (mm) 440 * 390 * 44;
Installation: Standard 19 inch 1U rackmount installation;
Physical Interface:
10 Gigabit optical port: 48*10 Gigabit optical ports, 10 Gigabit optical port adaptive connection Gigabit optical, type SFP/SFP+/LC;
Uplink optical ports: 2 40 uplink optical ports, type QSFP. 4 x 100 uplink optical ports, type QSFP28;
Console port: manage serial port, used for command line management, type RS232;
AUX debug port: out-of-band management interface for Telnet/SSH/WEB login control, type RJ45;
Working environment:
Operating temperature: -15C~55C;
Storage temperature: -40C~70C;
Relative humidity: 10%~90%, non-condensing;
Power consumption:
Power supply specifications: 1+1 redundant power supply, AC/DC optional;
Input power: AC: input 90~ 264V, 47 ~ 67Hz; DC: -36V~ -72V；
Power consumption of the whole machine: full load power consumption ≤ 180W, idle power consumption ≤25W;
Mechanical structure:
Chassis shell: metal shell, air-cooled heat dissipation;
Power supply fan: modular design of power supply and fan, support hot swappable, support fan speed control and alarm detection;
Chassis size: dimensions (length * width * height) (mm) 440 * 390 * 44;
Installation: Standard 19 inch 1U rackmount installation;
