HOP28111-8Transcoder-BISS -AC3

HOP28111-8 in 1 Transcoder with BISS and AC3


  • Support 8*IP (SPTS/MPTS) input plus 4*tuners input with 4 CAM/CI slots
  • Support 8*SPTS & 1*MPTS (UDP/RTP) output; 1 ASI output
  • Video Trans-coding: MPEG-2 SD/HD and H.264 SD/HD any-to-any
  • Audio Trans-coding: LC-AAC, MP2 and AC3 any-to-any or pass-through;
  • Support maximal 8 SD or 4 HD programs trans-coding
  • Support maximal 8 channel audio trans-coding
  • Support HD and SD resolutions
  • Support CBR and VBR rate control
  • Support CC (closed caption)
  • Support BISS descrambling
  • Support IP out with null packet filtered
  • Advanced de-multiplexing
  • LCD & Key board local control; web-based NMS management

This image for Image Layouts addon
HOP28111 is a professional bidirectional trans-coder to convert video between H.264 and MPEG-2 format and also to trans-code between HD and SD programs simultaneously. It is equipped with 4 tuner inputs to receive channels directly from satellite. And, each tuner is accompanied with a CAM/CI slot to descramble the encrypt content.
This image for Image Layouts addon
In addition, IP content can also be received and trans-coding processed. HOP28111.1 will at last output MPTS & SPTS through the DATA port (net port) or ASI port. This trans-coder supports advanced multiplexing and can effectively provide operators with real-time code rate switch and optimize the video with its high performance.

Stream In
MPTS/SPTS over UDP/RTP, 1000M Base-T Ethernet Interface/SFP interface
4 * (DVB-S/S2/C/T/ISDB-T/ATSC Optional) Tuners

BISS Descramble
8 programs

Stream Out
8*SPTS & 1*MPTS over UDP/RTP, 1000M Base-T Ethernet Interface (UDP/RTP uni-cast / multicast) /SFP interface
1*ASI (as a copy of one of the 8 SPTS or the MPTS) output, BNC interface

System Function
LCD & Key board control; web-based NMS management
Ethernet software upgrade

Dimensions 430mm×405mm×45mm (WxDxH)
Approx weight 4.8 Kg
Temperature range 0~45℃(Operation), -20~80℃(Storage)
Power requirements AC 200V-240V, 50/60Hz, 2A
Power consumption 20W
