HOP3508C 8*XGPON COMBO OLT with 8*10GE and 2*100GE uplink

HOP3508C-8XGSPON-8P10GE-2P100GE-OLT
Features:
  • Rich Layer 2 and Layer 3 switching features and flexible management methods
  • Support multiple link redundancy protocols such as FlexLink/STP/RSTP/MSTP/ERPS/LACP
  • Support RIP、OSPF、BGP、ISIS、IPV6
  • Safe DDOS and virus attack protection
  • Support power redundancy backup, support power pluggable
  • Support ONU automatic registration
  • Support power failure alarm
  • Compliant with ITU-T G.987/G.988 standard
  • 100 KM transmission distance
  • 1:256 maximum splitting ratio
  • Standard OMCI management functions
  • Flexibly compatible with any brand of ONT
  • ONU batch software upgrade
  • Support 4K VLAN 802.1Q
  • Supports VLAN based on port, MAC and protocol
  • Support dual Tag VLAN function, port-based static QinQ and flexible QinQ functions
  • Support ARP learning and aging
  • Supports creating VLAN Layer 3 interfaces and configuring static IPv4/IPv6 addresses
  • Support static routing configuration
  • Support RIP/OSPF protocol function
  • Support VRRP protocol function
  • Support standard and extended ACL
  • Support ACL policy based on time period
  • Provide flow classification and flow definition based on IP header information such as source/destination MAC address, VLAN, 802.1p, ToS, DSCP, source/destination IP address, L4 port number, protocol type, etc.
This image for Image Layouts addon
The HOP3508C OLT is an OLT control center with GPON, XGPON, XGSPON combo technology with a rate of 1 to 256 users, for advanced projects. With 8 combo ports and 8 10G uplinks and 2 100G uplinks and NMS accesses, it provides a wide range of network features for various solutions. Houper OLT center is able to connect to various brands of modems, switches and OLT with its reliability, stability and expandability.
This image for Image Layouts addon
It supports all standard OLT protocols and provides many fast and easy features for programming and configuring the device. Among its other advantages, there is the reliable redundant power. Its medium dimensions makes it very suitable and economical for industrial, home, corporate and organizational projects.
Physical Interface:
  • COMBO port: 8 GPON ports, type COMBO GPON EPON XGPON XGSPON SFP
  • Uplink optical port: 8*10GE/GE SFP + 2*100G QSFP28
  • Console port: manage serial port, used for device command line management, type RS232;
  • AUX debug port: out-of-band management interface for device Telnet/SSH/WEB login control, type RJ45;
Power consumption:
  • Power supply specifications: 1+1 redundant power supply, AC/DC;
  • Input power: AC: input 100 ~ 240V, 47 ~ 63Hz; DC 36-75V;
  • Power consumption of the whole machine: full load power consumption ≤65W, idle power consumption ≤ 25W;


Mechanical structure:
  • Chassis shell: die-cast aluminum shell, natural heat dissipation;
  • Chassis size: dimensions (length * width * height) (mm) 370x295x152mm;
  • Installation: pole or wall hanging;
