HOP28112 24*DVB-S-T-C to IP, IPTV Gateway

HOP28112-DVB-IP-Gateway


Features:
  • Support 24 FTA DVB- S/S2/S2X input, 1 ASI input, 1USB input
  • Support BISS descrambling
  • Support DisEqc function
  • 24 MPTS+2 MPTS(ASI and USB port) or 1024 SPTS output (MPTS and SPTS output switchable)
  • 2 GE output (IP address and port number of GE1 and GE2 are different), up to 850Mbps---SPTS
  • 2 independent GE output port, GE1（512 SPTS）+ GE2（512 SPTS）--- ( total 26 MPTS )
  • Support PID filtering, re-mapping (Only for SPTS output)
  • Support “Null PKT Filter” function (Only for MPTS output)
  • Support Web operation
This image for Image Layouts addon
HOP28112 Tuner to IP Gateway is a head-end interface conversion device which supports MPTS and SPTS output switchable. It supports 24 MPTS+2 MPTS(ASI and USB) or 1024 SPTS output over UDP and RTP/RTSP protocol.
This image for Image Layouts addon
It is integrated with tuner demodulation (or ASI input) and gateway function, which can demodulate the signal from 24 tuners into IP package, or directly convert the TS from ASI input and tuner into IP package, then output the IP package through different IP address and ports. BISS function is also embedded for tuner input to descramble your tuner input programs.


Physical Interface:

Input
24 tuners input +1 ASI input +1 USB input---SPTS/MPTS output

Output
1024 SPTS IP output over UDP and RTP/RTSP protocol through GE1 and GE2 port (IP address and port number of GE1 and GE2 are different) , Unicast and Multicast
26 MPTS IP output (for Tuner/ASI/USB pass-through) over UDP and RTP/RTSP protocol through GE1 and GE2 port, Unicast and Multicast

System
Web based management
Ethernet software upgrade

Miscellaneous
Dimension 482mm×230mm×44mm (W×L×H)
Approx weight 2.5kg
Environment 0~45℃(work); -20~80℃（Storage）
Power requirements 100~240VAC, 50/60Hz
Power consumption 20W
