HOP5750-30TX-24 Ports 2.5G- 6 Ports 10G uplink switch

HOP5750-30TX-24P2.5G-6P10G

The HOP5750-30TX switch has 24 ports with 2.5G of capacity, and 6 ports with 10G of capacity. This switch is made by HOUPER Company. It is one of the HOP5750 series switches that are sold in the network equipment market. This model of switch allows you to connect up to 2.5 gigabytes per port. As a Layer 3 switch, it has extremely high switching capacity, and supports multi-port reflective analysis and service flow-based image analysis. It also supports the mechanism of security filters such as ACL.
Specifications :

  • 24*2.5G ports,6*10 Gigabit optical ports,10 Gigabit optical ports can beadaptive to Gigabit;
  • Ultra-high switching capacity, support full port wire-speed forwarding performance;
  • Support weak Layer 3 access, support full port hardware Layer 3 wire-speed forwarding performance;
  • High-performance low-power network processor, support for green Ethernet line sleep capability, low device power consumption;
  • Support IPv4/IPv6 dual-stack platform, support RIP/OSPF and other routing protocols
  • Support VRRP/ERPS/MSTP/FlexLink/MonitorLink and other link redundancy and network redundancy protocols;
  • Support ACL security filtering mechanism, provide MAC, IP, L4 port and port level security control functions
  • Support Ethernet OAM 802.3ag(CFM),802.3ah(EFM) and other Ethernet link detection mechanisms
  • Supports remote user authentication based on Tacacs+/Radius, and supports Local user authentication
  • Supports SP/WRR/SP+WRR priority algorithm to ensure the transmission of various priority traffic flows on demand
  • Support IPv4/IPv6 static routing function;
  • Supports multi-port mirroring analysis and service flow-based image analysis.
  • Support static and flexible QinQfunction;
  • Support IPV4/6unicast routing in the policy, support flexible forwarding policy;
  • Supports CLI command line management based on serial port, Telnet, and SSHv2 mode
  • Support RFC1213 SNMP network management;
  • Supports configuration management based on WEB pages;
This image for Image Layouts addon
The switch is suitable for equipment that needs bandwidth of more than 1 gigabyte and less than 10 gigabytes. Among them, we can point out the computers of educational centers or the systems of a commercial company. At the end, all information will be placed in the uplink on ten-gigabyte bandwidth for transmission.
This image for Image Layouts addon
In addition, the switch can be used for transmitting video information on the IPTV network, as well as in public centers for connecting modems and wireless routers in airports, subways, commercial and office centers.
  • Product Specifications:
  • Physical Interface:

10 Gigabit optical port: 6*10 Gigabit optical ports, 10 Gigabit optical port adaptive connection Gigabit optical, type SFP/SFP+/LC;
2.5G port: 24*2.5G ports, the port can beadaptive10/100/1000M, type RJ45;
Console port: manage serial port, used for command line management, type RS232;

  • Working environment:

Operating temperature: -15C~55C;
Storage temperature: -40C~70C;
Relative humidity: 10%~90%, non-condensing;

  • Power consumption:

Power supply specifications: single power supply,AC
Input power: AC: input 90~264V, 47~67Hz;
Power consumption of the whole machine: full load power consumption ≤22W, idle power consumption ≤ 13W;

  • Mechanical structure:

Chassis shell: metal shell, air-cooled heat dissipation;
Chassis size: dimensions (length * width * height) (mm) 440 * 210 * 44;
Installation: Standard 19 inch 1U rackmount installation;
