HOP28108-HDMI-SDI-Encoder
HOP28108-Multi Channel Encoder
Features:
- Video Encoding: HEVC/H.265 & MPEG 4 AVC/H.264
- Audio Encoding: MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough
- Ultra Low Bit Rate: Save 75% Bandwidth
- Enhance Picture Quality: Advanced Compressing Algorithm
- Advanced Pretreatment: De-interlacing, Noise Reduction, Sharpening
- OSD (Logo, QR Code) insertion—Optional as per order
- STB Available with Ensurity CAS
- De-interlacing, Noise Reduction, Sharpening
Houper HOP28108 encoder is a Multi-Channel Encoder that converts HDMI and SDI input signals to IP. This advanced equipment has the ability to convert several HDMI and SDI channels to one or more IP channels.
In addition, the device has the ability to convert all types of audio and video protocols to each other. It is capable of intelligently reducing noise, OSD and logo insertion in Full HD quality, compressing images and sounds, reducing bandwidth by 75%.
Input
4/8/12×HD-SDI or HDMI(1.4) input for option, HDCP 1.4
Video Encoding : HEVC/H.265 , MPEG-4 AVC/H.264
Audio Encoding : MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough
Audio Gain : 0~255
Stream output
1 MPTS and 4 SPTS output over UDP/RTP/RTSP per module, Base-T Ethernet interface (1000M/100M self-adaption) (unicast/ multicast)
IP null packet filterd
System
Web based management
Ethernet software upgrade
Miscellaneous
Dimension (W× L× H)482mm×328mm×44mm
Approx weight 5kg
Temperature 0~45℃(work),-20~80℃（Storage）
PowerAC 100V-220V±10%, 50/60Hz
